Geared Low speed Electric Mixers

The GMW geared mixers are manufactured using a worm driven gearbox with a hollow shaft.

The mixer shaft is precision machined to suit and  be fitted with a keyway.  The impeller is a three bladed flat type manufactured in 316 stainless steel.  The mixer blades have a large surface area to ensure efficient mixing.

Also available with plastic coated propellers and shafts to provide greater chemical resistance.

Key Features:

Applications:  light to medium duty in Effulent and Water Treatment Industry

Construction: Stainless Steel shafts and propellers

Availability:  Approx 1 week

Details

CSS REFDESCRIPTIONPRICEEnquire
AML-9Geared Mixer 65 RPM with PVC shethed 930mm long shaft & 200mm Ø impeller fitted 240 VAC motor£575.00Enquire
GMW0Geared Mixer with 10" Ø impeller fitted 0.09 kW motor 415 volt£619.00Enquire
GMW1Geared Mixer with 10" Ø impeller fitted 0.18 kW motor 415 volt£646.00Enquire
GMW1-SP2Geared Mixer with 10" Ø impeller fitted 0.18 kWmotor 240 volt£762.00Enquire
GMW1-SP1Geared Mixer with 10"Ø impeller fitted 0.18 kW motor 110 volt£821.00Enquire
GMW11Geared Mixer with 10" Ø impeller fitted 0.37kW motor 415 volt£660.00Enquire
GMW11-SP2Geared Mixer with 10" Ø impeller fitted 0.37 kW motor 240 volt£841.00Enquire
GMW11-SP1Geared Mixer with 10" Ø impeller fitted 0.37kW motor 110 volt or£913.00Enquire

Documents

TitleDescriptionDownload
Mixers Installation sheetDownload
Geared Mixer Data sheetDownload
