Watson Marlow Qdos 20 Pumps

Watson Marlow Qdos Chemical Metering & Dosing Pump.

Qdos peristaltic chemical metering and dosing pumps, which deliver flow rates that remain constant up to 9 bar, give users a unique advantage over diaphragm metering pumps.

With extended maintenance intervals, Qdos pumps reduce process downtime and lower the overall cost of ownership

Features and benefits

  • Flow rates from 0.1 to 2000 ml/min at up to 9 bar
  • Simple drop-in installation eliminates ancillary equipment
  • Reduced maintenance with single, no-tools, component replacement
  • Cost of ownership is less than that of a diaphragm pump
  • Cut chemical cost through higher accuracy metering
  • No backpressure valves, pulsation dampener, degassing valves, foot valves, strainers or float switches

Details

CSS RefDescriptionPrice
0M0.154L.GLUQdos 20 PU Peristaltic pump Universal 4-20mA input - left£2,304.00
0M0.154L.GRUQdos 20 PU Peristaltic pump Universal 4-20mA input - Right£2,304.00
0M0.155L.GLUQdos 20 PU Univ+ 4-20mA input / output - Left£2,634.00
0M0.155L.GRUQdos 20 PU Univ+ 4-20mA input / output - Right£2,634.00
0M0.154R.GLUQdos 20 PU Uni 24v Relay I/O 4-20mA input - Left£2,454.00
0M0.154R.GRUQdos 20 PU Uni 24v Relay I/O 4-20mA input - Right£2,454.00
0M0.155R.GLUQdos 20 PU Uni+ 24v Relay I/O 4-20mA input / output - Left£2,814.00
0M0.155R.GRUQdos 20 PU Uni+ 24v Relay I/O 4-20mA input / output - Right£2,814.00
0M0.184L.GLUQdos 20 SEBS Peristaltic pump Universal 4-20mA input - left£2,316.00
0M0.184L.GRUQdos 20 SEBS Peristaltic pump Universal 4-20mA input - Right£2,316.00
0M0.185L.GLUQdos 20 SEBS Univ+ 4-20mA input / output - Left£2,730.00
0M0.185L.GRUQdos 20 SEBS Univ+ 4-20mA input / output - Right£2,730.00
0M0.184R.GLUQdos 20 SEBS Uni 24v Relay I/O 4-20mA input - Left£2,532.00
0M0.184R.GRUQdos 20 SEBS Uni 24v Relay I/O 4-20mA input - Right£2,532.00
0M0.185R.GLUQdos 20 SEBS Uni+ 24v Relay I/O 4-20mA input / output - Left£2,970.00
0M0.185R.GRUQdos 20 SEBS Uni+ 24v Relay I/O 4-20mA input / output - Right£2,970.00

Documents

TitleDescriptionDownload
Qdos Range Brochure (EN)Download
